Cantidad: | |
---|---|
NC | Rs | Imax | Î | WN | Ls | D x L | Dibujo | m | Orden No. | |
(uF) | (mΩ) | (a) | (KA) | (WS) | (nH) | (milímetro) | (Kilogramo) | |||
La O.N.U 700VDC nosotros 1050v Ur 200V U t-t UTC de 1050 VDC 3000 VAC | ||||||||||
370 | 2.1 | 40 | 2.0 | 86 | 50 | Φ76 x 130 | UN、 D DEL、 C DEL、 B | 0.7 | AG.H13 0K70-3706D76 | |
440 | 1.8 | 40 | 2.3 | 103 | 50 | Φ76 x 145 | UN、 D DEL、 C DEL、 B | 0.8 | AG.H14 0K70-4406D76 | |
470 | 1.7 | 55 | 2.5 | 110 | 40 | Φ86x 130 | UN、 D DEL、 C DEL、 B | 0.9 | AG.H13 0K70-4706D86 | |
560 | 1.4 | 40 | 3.0 | 132 | 60 | Φ76 x 181 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H18 0K70-5606D76 | |
590 | 1.3 | 55 | 3.1 | 137 | 40 | Φ86x 145 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H14 0K70-5906D86 | |
730 | 1.1 | 55 | 3.9 | 171 | 50 | Φ86x 181 | UN、 D DEL、 C DEL、 B | 1.2 | AG.H18 0K70-7306D86 | |
1030 | 1.0 | 55 | 5.1 | 252 | 70 | Φ86x 225 | UN、 D DEL、 C DEL、 B | 1.5 | AG.H22 0K70-1037D86 | |
La O.N.U 900VDC nosotros 1350v Ur 200V U t-t UTC de 1350 VDC 3000 VAC | ||||||||||
350 | 2.1 | 40 | 2.0 | 148 | 50 | Φ76 x 130 | UN、 D DEL、 C DEL、 B | 0.7 | AG.H13 0K90-3506D76 | |
410 | 1.2 | 40 | 2.3 | 178 | 50 | Φ76 x 135 | UN、 D DEL、 C DEL、 B | 0.8 | AG.H13 0K90-4106D76 | |
470 | 1.0 | 55 | 2.5 | 191 | 40 | Φ86x 135 | UN、 D DEL、 C DEL、 B | 0.9 | AG.H13 0K90-4706D86 | |
540 | 1.4 | 40 | 3.0 | 229 | 60 | Φ76 x 181 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H18 0K90-5406D76 | |
560 | 1.3 | 55 | 3.1 | 238 | 40 | Φ86x 145 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H14 0K90-5606D86 | |
700 | ~!phoenix_var10!~~!phoenix_var11!~~!phoenix_var12!~~!phoenix_var13!~~!phoenix_var14!~~!phoenix_var15!~~!phoenix_var16!~~!phoenix_var17!~~!phoenix_var18!~~!phoenix_var19!~~!phoenix_var20!~~!phoenix_var21!~~!phoenix_var22!~~!phoenix_var23!~~!phoenix_var24!~~!phoenix_var25!~~!phoenix_var26!~~!phoenix_var27!~~!phoenix_var28!~~!phoenix_var29!~~!phoenix_var30!~~!phoenix_var31!~~!phoenix_var32!~~!phoenix_var33!~~!phoenix_var34!~~!phoenix_var35!~~!phoenix_var36!~~!phoenix_var37!~
NC | Rs | Imax | Î | WN | Ls | D x L | Dibujo | m | Orden No. | |
(uF) | (mΩ) | (a) | (KA) | (WS) | (nH) | (milímetro) | (Kilogramo) | |||
La O.N.U 700VDC nosotros 1050v Ur 200V U t-t UTC de 1050 VDC 3000 VAC | ||||||||||
370 | 2.1 | 40 | 2.0 | 86 | 50 | Φ76 x 130 | UN、 D DEL、 C DEL、 B | 0.7 | AG.H13 0K70-3706D76 | |
440 | 1.8 | 40 | 2.3 | 103 | 50 | Φ76 x 145 | UN、 D DEL、 C DEL、 B | 0.8 | AG.H14 0K70-4406D76 | |
470 | 1.7 | 55 | 2.5 | 110 | 40 | Φ86x 130 | UN、 D DEL、 C DEL、 B | 0.9 | AG.H13 0K70-4706D86 | |
560 | 1.4 | 40 | 3.0 | 132 | 60 | Φ76 x 181 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H18 0K70-5606D76 | |
590 | 1.3 | 55 | 3.1 | 137 | 40 | Φ86x 145 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H14 0K70-5906D86 | |
730 | 1.1 | 55 | 3.9 | 171 | 50 | Φ86x 181 | UN、 D DEL、 C DEL、 B | 1.2 | AG.H18 0K70-7306D86 | |
1030 | 1.0 | 55 | 5.1 | 252 | 70 | Φ86x 225 | UN、 D DEL、 C DEL、 B | 1.5 | AG.H22 0K70-1037D86 | |
La O.N.U 900VDC nosotros 1350v Ur 200V U t-t UTC de 1350 VDC 3000 VAC | ||||||||||
350 | 2.1 | 40 | 2.0 | 148 | 50 | Φ76 x 130 | UN、 D DEL、 C DEL、 B | 0.7 | AG.H13 0K90-3506D76 | |
410 | 1.2 | 40 | 2.3 | 178 | 50 | Φ76 x 135 | UN、 D DEL、 C DEL、 B | 0.8 | AG.H13 0K90-4106D76 | |
470 | 1.0 | 55 | 2.5 | 191 | 40 | Φ86x 135 | UN、 D DEL、 C DEL、 B | 0.9 | AG.H13 0K90-4706D86 | |
540 | 1.4 | 40 | 3.0 | 229 | 60 | Φ76 x 181 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H18 0K90-5406D76 | |
560 | 1.3 | 55 | 3.1 | 238 | 40 | Φ86x 145 | UN、 D DEL、 C DEL、 B | 1.0 | AG.H14 0K90-5606D86 | |
700 | ~!phoenix_var10!~~!phoenix_var11!~~!phoenix_var12!~~!phoenix_var13!~~!phoenix_var14!~~!phoenix_var15!~~!phoenix_var16!~~!phoenix_var17!~~!phoenix_var18!~~!phoenix_var19!~~!phoenix_var20!~~!phoenix_var21!~~!phoenix_var22!~~!phoenix_var23!~~!phoenix_var24!~~!phoenix_var25!~~!phoenix_var26!~~!phoenix_var27!~~!phoenix_var28!~~!phoenix_var29!~~!phoenix_var30!~~!phoenix_var31!~~!phoenix_var32!~~!phoenix_var33!~~!phoenix_var34!~~!phoenix_var35!~~!phoenix_var36!~~!phoenix_var37!~
